Trigonal 3D wall tiles | EQUAL

EQUAL is shaped by balance, its beveled faces and hexagonal flow catching light in motion. Its three-dimensional geometry of the 3D wall tiles rises and falls in sequence, creating a surface that’s both uniform and unpredictable. As the light changes, so does the wall — never static, always shifting.

TECHNICAL SPECIFICATIONS

Dimensions: L 222mm x W 220mm  // 8.74" × 8.66"

Thickness: 20mm – 40mm  // 0.79" – 1.57"

Weight/tile: 860g // 1.90 lbs

Weight/m²: 27,1kg  // 5.55 lbs/ft²

Area: 31.5 tiles in a m²  // 2.93 tiles / ft²

Compressive strength: 11,600 psi – 13,500 psi // 80–93 MPa

Flexural strength: 2,800 psi – 3,300 psi // 19–23 MPa

Impact Resistance: High / Class I

Density: 1,400–1,500 kg/m³ // 87.4–93.6 lb/ft³

Thermal expansion: 9.6 to 10.3 × 10⁻⁶ /°C // 5.3 to 5.7 × 10⁻⁶ in/in/°F

Thermal Insulation (R-value of tile): ~0.085 m²·K/W // 0.484 ft²·°F·hr/BTU

Fire Classification: Non-combustible

Water Absorption (sealed): <1%

Available on Order - Price per SQM - Custom orders ship in 14-18 weeks - Minimum Quantity applies
